TURNING Holders

Right-hand shown
SN

EXTERNAL TURNING
WF
B
KAPR LH H
LF
M
MSBN
H B WF LF LH A MIID
External turning (KAPR 75°)
R L THREADING
R
NT-MSBN /L2020K12 h h 20 20 17 125 37
12 NT-MSBN R /L2525M12 h h 25 25 22 150 37 SN 1204
NT-MSBN R /L3232P12 f f 32 32 27 170 42
R
NT-MSBN /L3232P19 f f 32 32 27 170 42
19 SN 1906
NT-MSBN R /L4040S19 f f 40 40 35 250 42
h stock standard, f non-standard stock

SHIM ECCENTRIC PIN CLAMP CLAMP SCREW WRENCH
GROOVING
Spare Parts

R
NT-MSBN /L2020K12
NT-MSBN R /L2525M12 NT-SH070 NT-SP010 NT-CS010 NT-SC010 NT-WR030
NT-MSBN R /L3232P12
NT-MSBN /L3232P19
R
NT-SH090 NT-SP050 NT-CS015 NT-SC070 NT-WR040
NT-MSBN R /L4040S19
MILLING
CARBIDE PCBN CERAMIC DIAMOND
Inserts

SN 1204 page 21 page 46 page 63 -
SN  1906 page 22 - - -

DRILLING

ACCESSORIES
