TURNING Holders

Right-hand shown
SN

TURNING EXTERNAL WF B

KAPR LH H
LF
M
MSSN
H B WF LF LH A MIID
External turning (KAPR 45°)
THREADING NT-MSSN /L2020K12 h h L 20 20 25 125 35
R
R
12 NT-MSSN R /L2525M12 h h 25 25 32 150 35 SN 1204
NT-MSSN R /L3232P12 f f 32 32 40 170 42
NT-MSSN /L3232P19 f f 32 32 40 170 42
R
19 SN 1906
NT-MSSN R /L4040S19 f f 40 40 40 250 42
h stock standard, f non-standard stock

SHIM ECCENTRIC PIN CLAMP CLAMP SCREW WRENCH
GROOVING Spare Parts

NT-MSSN /L2020K12
R
NT-MSSN R /L2525M12 NT-SH070 NT-SP010 NT-CS010 NT-SC010 NT-WR030
NT-MSSN R /L3232P12
NT-MSSN /L3232P19
R
NT-SH090 NT-SP050 NT-CS015 NT-SC070 NT-WR040
NT-MSSN R /L4040S19
MILLING CARBIDE PCBN CERAMIC DIAMOND

Inserts

SN 1204 page 21 page 46 page 63 -
SN  1906 page 22 - - -

DRILLING

ACCESSORIES
