TURNING Holders

Right-hand shown
DN

TURNING EXTERNAL

WF B

KAPR LH H
LF
P
PDJN
H B WF LF LH A MIID
External turning (KAPR 93°)
THREADING 15 NT-PDJN /L2525M1506 h h L 25 25 32 150 36 DN 1506
R
R
h stock standard

SHIM PLUG LEVER LEVER SCREW WRENCH
Spare Parts

NT-PDJN /L2525M1506 NT-SH020 NT-SR020 NT-LL020 NT-SC020 NT-WR030
R
GROOVING

CARBIDE PCBN CERAMIC DIAMOND
Inserts

DN 1506 page 16 page 43 page 59 page 75

MILLING

DRILLING

ACCESSORIES
