TURNING Holders

Right-hand shown
CN

TURNING
EXTERNAL
B
WF KAPR
LH H
LF
D
DCLN
H B WF LF LH A MIID
External Turning (KAPR 95°)
R L THREADING
NT-DCLN /L1616H09X h h 16 16 20 100 33
R
09 NT-DCLN R /L2020K09X h h 20 20 25 125 30 CN  0903
NT-DCLN R /L2525M09X h h 25 25 32 150 30
NT-DCLN /L2020K12X h h 20 20 25 125 40
R
12 NT-DCLN /L2525M12X h h 25 25 32 150 36 CN  1204
R
NT-DCLN /L3225P12X h h 32 25 32 170 36
R
h stock standard
SHIM SHIM SCREW SHIM WRENCH CLAMP SPRING CLAMP SCREW CLAMP WRENCH GROOVING
Spare Parts

NT-DCLN /L1616H09X
R
NT-DCLN R /L2020K09X NT-SH012 NT-ST031 NT-WR020 NT-CS250 NT-SG250 NT-SC250 NT-TX15
NT-DCLN R /L2525M09X
R
NT-DCLN /L2020K12X
NT-DCLN /L2525M12X NT-SH030 NT-ST200 NT-WR025 NT-CS200 NT-SG200 NT-SC200 NT-TX20
R
NT-DCLN /L3225P12X
R
MILLING
CARBIDE PCBN CERAMIC DIAMOND
Inserts

CN 0903 page 10 - - -
CN  1204 page 10 page 40 page 57 page 72

DRILLING

ACCESSORIES
