TURNING Holders

Right-hand shown STEEL
TP

TURNING INTERNAL KAPR DCON max 3XD

WF

LF
GAMO
S DMIN
S STUP
DMIN DCON WF LF GAMO A MIID
Internal turning (KAPR 93°)
THREADING NT-S10K-STUP /L09 h h L 12 10 6 125 8°
R
R
09
NT-S12M-STUP /L09 h h 14 12 7 150 5° TP 0902
R
NT-S10K-STUP /L11 h h 12 10 6 125 8°
R
R
NT-S12M-STUP /L11 h h 14 12 7 150 7°
11 TP 1103
R
NT-S16K-STUP /L11 h h 18 16 9 180 4°
NT-S20R-STUP /L11 h h 22 20 11 200 2°
R
h stock standard
GROOVING Spare Parts INSERT SCREW INSERT WRENCH

NT-S10K-STUP /L09
R
NT-ST005 NT-FT08
NT-S12M-STUP R /L09
NT-S10K-STUP /L11
R
NT-ST014
NT-S12M-STUP /L11
R
NT-FT10
NT-S16K-STUP /L11
R
NT-ST015
NT-S20R-STUP /L11
R
MILLING
CARBIDE PCBN CERAMIC DIAMOND
Inserts
TP 0902 page 28 page 49 - page 79
TP  1103 page 28 page 49 - page 79

DRILLING

ACCESSORIES
