TURNING Holders

Right-hand shown STEEL
TN

TURNING INTERNAL KAPR DCON max 3XD

WF

LF
GAMO
M DMIN
S MTUN
DMIN DCON WF LF GAMO A MIID
Internal turning (KAPR 93°)
THREADING NT-S20R-MTUN /L16 h h L 25 20 13 200 17°
R
R
NT-S25R-MTUN /L16 h h 32 25 17 200 12°
R
16 NT-S32S-MTUN /L16 h h 40 32 22 250 10° TN 1604
R
NT-S40T-MTUN /L16 h h 50 40 27 300 10°
R
NT-S50U-MTUN R /L16 h h 63 50 35 350 8°
NT-S40T-MTUN /L22 f f 50 40 27 300 15°
R
22 TN 2204
NT-S50U-MTUN R /L22 f f 63 50 35 350 12°

h stock standard, f non-standard stock
GROOVING SHIM ECCENTRIC PIN PIN WRENCH CLAMP CLAMP SCREW CLAMP WRENCH
Spare Parts

R
NT-S20R-MTUN /L16 NT-CS030 NT-SC030 NT-WR025
- NT-SP030
NT-S25R-MTUN /L16 NT-SC008
R
NT-S32S-MTUN /L16 NT-WR020
R
NT-CS010 NT-WR030
NT-S40T-MTUN R /L16 NT-SH005 NT-SP020 NT-SC010
NT-S50U-MTUN R /L16
MILLING NT-S40T-MTUN /L22 NT-SH008 NT-SP010 NT-WR030 NT-CS070 NT-SC070 NT-WR040
R
/L22
NT-S50U-MTUN R
CARBIDE PCBN CERAMIC DIAMOND
Inserts

TN 1604 page 25 page 48 page 65 page 78
DRILLING TN  2204 page 25 - - -
