TURNING Holders

Right-hand shown STEEL
CN

INTERNAL max 3XD TURNING
DCON
KAPR
WF
INTERNAL
GAMO LF COOLANT
P DMIN

A PCLN
DMIN DCON WF LF GAMO A MIID
Internal turning (KAPR 95°)
R L THREADING
R
NT-A25R-PCLN /L12 h h 32 25 17 200 11°
12 NT-A32S-PCLN /L12 h h 40 32 22 250 11° CN  1204
R
NT-A40T-PCLN /L12 h h 50 40 27 300 10°
R
h stock standard

SHIM PLUG LEVER LEVER SCREW WRENCH
Spare Parts
GROOVING

NT-A25R-PCLN /L12 - NT-SR015 NT-LL015 NT-SC015 NT-WR025
R
R
NT-A32S-PCLN /L12
NT-SH035 NT-SR020 NT-LL020 NT-SC025 NT-WR030
R
NT-A40T-PCLN /L12
CARBIDE PCBN CERAMIC DIAMOND
Inserts
MILLING
CN 1204 page 10 page 40 page 57 page 72

DRILLING

ACCESSORIES

105
