TURNING Holders

Right-hand shown STEEL
CC

INTERNAL max 3XD TURNING
DCON
KAPR
WF
GAMO LF
S DMIN
S SCLC
DMIN DCON WF LF GAMO A MIID
Internal turning (KAPR 95°)
R L THREADING
R
NT-S08H-SCLC /L06 h h 10 8 5 100 13°
NT-S10K-SCLC /L06 h h 12 10 6 125 12°
R
06 CC  0602
NT-S12M-SCLC /L06 h h 14 12 7 150 9°
R
NT-S16Q-SCLC R /L06 h h 18 16 9 180 7°
NT-S12M-SCLC /L09 h h 14 12 7 150 13°
R
09 NT-S16Q-SCLC /L09 h h 18 16 9 180 9° CC  09T3
R
NT-S20R-SCLC R /L09 h h 22 20 11 200 5°
R
NT-S20R-SCLC /L12 h h 25 20 13 200 8°
CC  1204
NT-S25R-SCLC R /L12 h h 32 25 17 200 8°
12
NT-S32S-SCLC /L12S h h 40 32 22 250 6°
R
CC  1204 GROOVING
NT-S40T-SCLC R /L12S h h 50 40 27 300 4°
h stock standard
SHIM SHIM SCREW SHIM WRENCH INSERT SCREW INSERT WRENCH
Spare Parts
NT-S08H-SCLC /L06 NT-ST006
R
NT-S10K-SCLC /L06
R
- - - NT-FT07 MILLING
NT-S12M-SCLC R /L06 NT-ST010
NT-S16Q-SCLC R /L06
NT-S12M-SCLC /L09
R
NT-ST025
NT-S16Q-SCLC R /L09 - - - NT-FT15
NT-S20R-SCLC R /L09 NT-ST030
NT-S20R-SCLC /L12
R
- - - NT-ST050 NT-FT15
NT-S25R-SCLC R /L12
NT-S32S-SCLC /L12S
R
NT-SH001 NT-SR001 NT-WR040 NT-ST007 NT-FT15
NT-S40T-SCLC R /L12S
DRILLING
CARBIDE PCBN CERAMIC DIAMOND
Inserts

CC 0602 page 8 page 39 - page 70
CC  09T3 page 8 page 39 page 56 page 70
CC  1204 page 8 - page 56 page 70
ACCESSORIES
