THREADING Indexable inserts

HC-PVD
CARBIDE
TPM Internal threading ISO513 JP5125

TURNING Size IC S D1 P 180
80
60
11 6.35 3.18 3.20 M 140
50
16 9.525 3.65 4.00 K 120
N

S 20
40
3 edges Stable machining, continuous cut H
GRADE APPLICATION AREA
THREADING d main application General machining, light interruption | Hardness + + Toughness | d
d
d
d
d
d applicable Unstable machining, interrupted cut d
pitch: 1.00 mm
M P M K S 11IR 100ISO-TPM RE 0.07 h
no. of passes 5÷8
pitch: 1.25 mm
125ISO-TPM RE 0.09 h
no. of passes 6÷9
pitch: 1.50 mm
150ISO-TPM RE 0.11 h
no. of passes 6÷9
pitch: 1.75 mm
175ISO-TPM RE 0.13 h
no. of passes 8÷11
pitch: 2.00 mm
GROOVING 16IR 200ISO-TPM RE 0.15 no. of passes 8÷11 h
pitch: 1.00 mm
RE 0.07
100ISO-TPM
h
no. of passes 5÷8
pitch: 1.25 mm
125ISO-TPM RE 0.09 h
no. of passes 6÷9
pitch: 1.50 mm
150ISO-TPM RE 0.11 h
no. of passes 6÷9
pitch: 1.75 mm
175ISO-TPM RE 0.13 h
no. of passes 8÷11
pitch: 2.00 mm
200ISO-TPM RE 0.15 h
no. of passes 8÷11
pitch: 2.50 mm
250ISO-TPM RE 0.18 h
no. of passes 10÷13
pitch: 3.00 mm
MILLING METRIC 60° 16IR 300ISO-TPM RE 0.22 no. of passes 12÷15 h
FULL PROFILE 20UN-TPM RE 0.09 no. of passes 6÷9 h
pitch: 24 TPI
h
UN P M K S
24UN-TPM
RE 0.08
no. of passes 5÷8
pitch: 20 TPI
pitch: 18 TPI
18UN-TPM
h
RE 0.10
pitch: 16 TPI
16UN-TPM RE 0.12 no. of passes 6÷9 h
no. of passes 7÷10
pitch: 14 TPI
14UN-TPM RE 0.13 h
no. of passes 8÷11
pitch: 12 TPI
12UN-TPM RE 0.16 h
no. of passes 8÷11
pitch: 8 TPI
DRILLING UNIFIED 60° 08UN-TPM RE 0.23 no. of passes 12÷15 h
NPT P M K S
16IR 18NPT-TPM RE 0.20 pitch: 18 TPI h
no. of passes 8÷11
pitch: 14 TPI
14NPT-TPM RE 0.22 h
no. of passes 10÷13
pitch: 11.5 TPI
NATIONAL PIPE TAPERED 60° 11.5NPT-TPM RE 0.25 no. of passes 12÷15 h
W P M K S pitch: 19 TPI
16IR 19W-TPM RE 0.17 h
no. of passes 6÷9
ACCESSORIES WHITWORTH 55° 14W-TPM RE 0.24 no. of passes 8÷11 h
pitch: 14 TPI
pitch: 11 TPI
h
11W-TPM
RE 0.30
no. of passes 9÷12
£
