DRILLING Indexable inserts

SPX 4 edges drilling inserts ISO513 JP5625 HC-PVD JP9635 HW JU6520
DRS PILOT
JP5530

60 60
Size IC S D1 RE P 220 220 TURNING
05 5.00 2.38 2.50 0.40 M 40
160
06 6.00 2.38 2.80 0.40 K 100 100
190 190
07 7.94 3.97 2.80 0.80 N 150
300
S
H
4 edges
GRADE APPLICATION AREA Stable machining d d d
d
d
d
d
d
d
d main application General machining | Hardness + + Toughness | d d d d THREADING
d
d
d
d
d
d
d applicable Unstable machining d d d d
d
GP P M K SPMX 050204-GP 6xD f n£ 0.08 0.10 0.12 h h h
9xD f n£ 0.06 0.08 0.10
GENERAL SPMX 060204-GP 6xD f n£ 0.08 0.10 0.12 h h h
9xD f n£ 0.06 0.08 0.10
SPMX 07T308-GP 6xD f n£ 0.09 0.11 0.13 h h h
9xD f n£ 0.07 0.09 0.11 h
6xD f n£ 0.05 0.07 0.09
ALUMINIUM AL N SPGX 060204-AL 9xD f n£ 0.04 0.06 0.08 h GROOVING
050204-AL
SPGX
6xD f n£ 0.05 0.07 0.09
9xD f n£ 0.04 0.06 0.08
polished surface SPGX 07T308-AL 6xD f n£ 0.06 0.08 0.10 h
9xD f n£ 0.05 0.07 0.09
h stock standard
DRSP interchangeable centering drill HEIGHT ADJUSTEMENT MILLING
DRS PILOT

Size DC OAL PL SIG
06 6 20 1.5 118°
08 8 25 2.1 118°

DRILLING
pilot height

GP P M K N DRSP 06-GP HSS TIN h MATERIAL 6xD 9xD
GENERAL P M K 1.0 mm 1.4 mm

DRSP 08-GP HSS TIN
h
N 1.5 mm 1.7 mm
ACCESSORIES
h stock standard
